Home > Products > Discrete Semiconductor Products > Transistors - FETs, MOSFETs - RF > MRFX1K80HR5

MRFX1K80HR5

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy MRFX1K80HR5 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	MRFX1K80HR5
Manufacturer	NXP Semiconductors / Freescale
Description	RF MOSFET LDMOS 65V NI-1230H-4S
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 271 pcs
Reference Price (In US Dollars)	1 pcs	10 pcs
Reference Price (In US Dollars)	$122.535	$117.359

Product parameter
Data sheet

Product parameter

Part Number	MRFX1K80HR5	Manufacturer	NXP Semiconductors / Freescale
Description	RF MOSFET LDMOS 65V NI-1230H-4S	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	271 pcs	Data sheet	MRFX1K80HR5 Intro MRFX1K80H Datasheet
Category	Discrete Semiconductor Products	Voltage - Test	65V
Voltage - Rated	182V	Transistor Type	LDMOS (Dual)
Supplier Device Package	NI-1230-4H	Series	-
Power - Output	1800W	Packaging	Cut Tape (CT)
Package / Case	NI-1230-4H	Other Names	568-13464 568-13464-1 568-13464-ND
Noise Figure	-	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Gain	24dB
Frequency	1.8MHz ~ 470MHz	Detailed Description	RF Mosfet LDMOS (Dual) 65V 200mA 1.8MHz ~ 470MHz 24dB 1800W NI-1230-4H
Current Rating	10µA	Current - Test	200mA
