Home > Products > RF/IF and RFID > RF Transceiver Modules > JN5168-001-M00Z

JN5168-001-M00Z

JN5168-001-M00Z

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy JN5168-001-M00Z with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	JN5168-001-M00Z
Manufacturer	NXP Semiconductors / Freescale
Description	RF TXRX MOD 802.15.4 TRACE ANT
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 6756 pcs
Reference Price (In US Dollars)	400 pcs	800 pcs
Reference Price (In US Dollars)	$4.986	$4.487

Product parameter
Data sheet

Product parameter

Part Number	JN5168-001-M00Z	Manufacturer	NXP Semiconductors / Freescale
Description	RF TXRX MOD 802.15.4 TRACE ANT	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	6756 pcs	Data sheet	JN5168-001-Mxx Datasheet JN516x Datasheet
Category	RF/IF and RFID	Voltage - Supply	2 V ~ 3.6 V
Utilized IC / Part	-	Series	-
Serial Interfaces	I²C, SPI, UART	Sensitivity	-95dBm
RF Family/Standard	802.15.4	Protocol	Zigbee®
Power - Output	2.5dBm	Packaging	Tape & Reel (TR)
Package / Case	27-SMD Module	Other Names	568-10327-2 935300515534 JN5168-001-M00Z-ND
Operating Temperature	-40°C ~ 85°C	Mounting Type	Surface Mount
Moisture Sensitivity Level (MSL)	3 (168 Hours)	Modulation	O-QPSK
Memory Size	256kB Flash, 4kB EEPROM, 32kB RAM	Manufacturer Standard Lead Time	13 Weeks
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Frequency	2.4GHz
Data Rate	-	Current - Transmitting	15.3mA
Current - Receiving	17mA	Antenna Type	Integrated, Trace
