Home > Products > Development Boards, Kits, Programmers > Evaluation and Demonstration Boards and Kits > IL700-01

IL700-01

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy IL700-01 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	IL700-01
Manufacturer	NVE Corporation
Description	IL700 ISOLATOR EVAL BOARD
Lead Free Status / RoHS Status	Contains lead / RoHS non-compliant

~~In Stock~~ 2128 pcs
Reference Price (In US Dollars)	1 pcs
Reference Price (In US Dollars)	$16.804

Product parameter
Data sheet

Product parameter

Part Number	IL700-01	Manufacturer	NVE Corporation
Description	IL700 ISOLATOR EVAL BOARD	Lead Free Status / RoHS Status	Contains lead / RoHS non-compliant
Quantity Available	2128 pcs	Data sheet	IL700 Series
Category	Development Boards, Kits, Programmers	Utilized IC / Part	IL710S-1E, IL712-3E, IL715-3E, IL716E
Type	Interface	Supplied Contents	Board(s)
Series	IsoLoop®	Secondary Attributes	-
Primary Attributes	-	Other Names	390-1137 IL70001
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Manufacturer Standard Lead Time	10 Weeks
Lead Free Status / RoHS Status	Contains lead / RoHS non-compliant	Function	Digital Isolator
Embedded	-	Detailed Description	IL710S-1E, IL712-3E, IL715-3E, IL716E Digital Isolator Interface Evaluation Board
