Home > Products > Development Boards, Kits, Programmers > Evaluation and Demonstration Boards and Kits > IL600-01

IL600-01

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy IL600-01 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	IL600-01
Manufacturer	NVE Corporation
Description	IL600 ISOLATOR EVAL BOARD
Lead Free Status / RoHS Status	Contains lead / RoHS non-compliant

~~In Stock~~ 2205 pcs
Reference Price (In US Dollars)	1 pcs
Reference Price (In US Dollars)	$16.768

Product parameter
Data sheet

Product parameter

Part Number	IL600-01	Manufacturer	NVE Corporation
Description	IL600 ISOLATOR EVAL BOARD	Lead Free Status / RoHS Status	Contains lead / RoHS non-compliant
Quantity Available	2205 pcs	Data sheet	IL600 Series
Category	Development Boards, Kits, Programmers	Utilized IC / Part	IL610A-1E, IL611-3E, IL613E, IL614-3E
Type	Interface	Supplied Contents	Board(s)
Series	IsoLoop®	Secondary Attributes	-
Primary Attributes	-	Other Names	390-1135 IL60001
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Manufacturer Standard Lead Time	10 Weeks
Lead Free Status / RoHS Status	Contains lead / RoHS non-compliant	Function	Digital Isolator
Embedded	-	Detailed Description	IL610A-1E, IL611-3E, IL613E, IL614-3E Digital Isolator Interface Evaluation Board
