Home > Products > Motors, Solenoids, Driver Boards/Modules > Stepper Motors > SM8-F20-HHE0

SM8-F20-HHE0

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy SM8-F20-HHE0 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	SM8-F20-HHE0
Manufacturer	NMB Technologies Corp.
Description	STEPPER MOTOR PM BIPOLAR 5V
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

	50 pcs	100 pcs	250 pcs
~~In Stock~~ 2652 pcs
Reference Price (In US Dollars)	1 pcs	5 pcs	10 pcs	25 pcs
	$13.773	$13.536	$13.299	$13.062
	$12.824	$12.634	$12.349

Product parameter
Data sheet

Product parameter

Part Number	SM8-F20-HHE0	Manufacturer	NMB Technologies Corp.
Description	STEPPER MOTOR PM BIPOLAR 5V	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	2652 pcs	Data sheet	SM8-20
Category	Motors, Solenoids, Driver Boards/Modules	Weight	-
Voltage - Rated	5VDC	Type	Permanent Magnet
Torque - Holding (oz-in / mNm)	-	Termination Style	Through Hole
Steps per Revolution	20	Step Angle	18°
Size / Dimension	Round - 0.315" Dia (8.00mm)	Series	-
Rotor Inertia	-	Other Names	P121386 Q9250466 SM8-20 SM8-20-ND
Operating Temperature	-10°C ~ 50°C	Mounting Hole Spacing	0.433" (11.00mm)
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Manufacturer Standard Lead Time	5 Weeks
Length - Shaft and Bearing	-	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Features	Round Shaft	Diameter - Shaft	0.039" (1.00mm)
Detailed Description	Bipolar Stepper Motor 5VDC	Coil Type	Bipolar
Coil Resistance	21 Ohms	Approvals	-
Accuracy	-
