WT29S
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy WT29S with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy WT29S with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | WT29S |
|---|---|
| Manufacturer | NKK Switches |
| Description | SWITCH TOGGLE DPDT 10A 125V |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $6.711 | $6.35 | $6.168 | $5.987 | ||
| 100 pcs | 250 pcs | 500 pcs | |||
| $5.805 | $5.624 | $4.717 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | WT29S | Manufacturer | NKK Switches |
|---|---|---|---|
| Description | SWITCH TOGGLE DPDT 10A 125V | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 7062 pcs | Data sheet | WT Series Toggle Datasheet |
| Category | Switches | Voltage Rating - DC | 30V |
| Voltage Rating - AC | 125V | Termination Style | Solder Lug |
| Switch Function | On-Off-Mom | Series | WT |
| Panel Cutout Dimensions | Circular - 12.50mm Dia | Packaging | Bulk |
| Other Names | WT29S-RO WT29S-RO-ND |
Operating Temperature | -30°C ~ 70°C |
| Mounting Type | Panel Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 16 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Ingress Protection | IP67 - Dust Tight, Waterproof | Illumination Voltage (Nominal) | - |
| Illumination Type, Color | - | Illumination | Non-Illuminated |
| Features | Epoxy Sealed Terminals | Electrical Life | 15,000 Cycles |
| Detailed Description | Toggle Switch DPDT Panel Mount | Current Rating | 10A (AC/DC) |
| Circuit | DPDT | Bushing Thread | M12 x 1 |
| Actuator Type | Standard Round | Actuator Material | Brass, Chrome Plated |
| Actuator Length | 17.50mm |
