WR12AF
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy WR12AF with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy WR12AF with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | WR12AF |
|---|---|
| Manufacturer | NKK Switches |
| Description | SWITCH ROCKER SPDT 15A 125V |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $4.356 | $3.92 | $3.811 | $3.703 | ||
| 100 pcs | 250 pcs | 500 pcs | 1000 pcs | ||
| $3.594 | $3.485 | $3.049 | $2.886 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | WR12AF | Manufacturer | NKK Switches |
|---|---|---|---|
| Description | SWITCH ROCKER SPDT 15A 125V | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 11178 pcs | Data sheet | WR Series Rocker Datasheet |
| Category | Switches | Voltage Rating - DC | 30V |
| Voltage Rating - AC | 125V | Termination Style | Quick Connect - 0.250" (6.3mm) |
| Switch Function | On-On | Series | WR |
| Panel Cutout Dimensions | Rectangular - 34.20mm x 17.20mm | Packaging | Bulk |
| Other Names | 360-2278 | Operating Temperature | -25°C ~ 85°C |
| Mounting Type | Panel Mount, Snap-In | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Mechanical Life | 30,000 Cycles | Manufacturer Standard Lead Time | 9 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Ingress Protection | IP67 - Dust Tight, Waterproof |
| Illumination Voltage (Nominal) | - | Illumination Type, Color | - |
| Features | Epoxy Sealed Terminals | Electrical Life | 15,000 Cycles |
| Detailed Description | Rocker Switch SPDT 15A (AC/DC) 125V Panel Mount, Snap-In | Current Rating | 15A (AC/DC) |
| Color - Actuator/Cap | Black | Circuit | SPDT |
| Actuator Type | Concave (Curved) | Actuator Marking | No Marking |
