Home > Products > Switches > Toggle Switches > S1B

S1B

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy S1B with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	S1B
Manufacturer	NKK Switches
Description	SWITCH TOGGLE SPST 5A 125V
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 5871 pcs
Reference Price (In US Dollars)	Get a quote

Product parameter

Product parameter

Part Number	S1B	Manufacturer	NKK Switches
Description	SWITCH TOGGLE SPST 5A 125V	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	5871 pcs	Data sheet
Category	Switches	Voltage Rating - DC	30V
Voltage Rating - AC	125V	Termination Style	Solder Lug
Switch Function	On-Off	Series	S
Panel Cutout Dimensions	Circular - 12.50mm Dia	Packaging	Bulk
Other Names	360-2678 S1B-ND S1B-RO S1B-RO-ND	Operating Temperature	-10°C ~ 70°C
Mounting Type	Panel Mount	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Ingress Protection	-
Illumination Voltage (Nominal)	-	Illumination Type, Color	-
Illumination	Non-Illuminated	Features	-
Electrical Life	25,000 Cycles	Detailed Description	Toggle Switch SPST Panel Mount
Current Rating	5A (AC/DC)	Circuit	SPST
Bushing Thread	M12 x 1	Actuator Type	Standard Round
Actuator Material	Brass, Chrome Plated	Actuator Length	17.50mm
