Home > Products > Switches > Pushbutton Switches > LB16SKG01-H

LB16SKG01-H

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy LB16SKG01-H with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	LB16SKG01-H
Manufacturer	NKK Switches
Description	SWITCH PUSHBUTTON SPDT 0.4VA 28V
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 7270 pcs
Reference Price (In US Dollars)	1 pcs
Reference Price (In US Dollars)	$4.599

Product parameter
Data sheet

Product parameter

Part Number	LB16SKG01-H	Manufacturer	NKK Switches
Description	SWITCH PUSHBUTTON SPDT 0.4VA 28V	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	7270 pcs	Data sheet	LB Series Snap-in Pushbuttons LB Series Datasheet
Category	Switches	Voltage Rating - DC	28V
Voltage Rating - AC	28V	Type	Standard
Termination Style	Solder, Quick Connect - 0.110" (2.8mm)	Switch Function	On-On
Series	LB	Panel Cutout Dimensions	Square - 16.20mm²
Packaging	Bulk	Other Names	360-3065 LB16SKG01-H-ND
Operating Temperature	-25°C ~ 70°C	Mounting Type	Panel Mount, Snap-In
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Mechanical Life	200,000 Cycles
Manufacturer Standard Lead Time	13 Weeks	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Ingress Protection	-	Illumination Voltage (Nominal)	-
Illumination Type, Color	-	Features	-
Electrical Life	100,000 Cycles	Detailed Description	Pushbutton Switch SPDT Standard Panel Mount, Snap-In
Current Rating	0.4VA (AC/DC)	Color - Actuator/Cap	Gray
Circuit	SPDT	Actuator Type	Square, Button
