Home > Products > Switches > Pushbutton Switches > LB15SKW01-05-CJ

LB15SKW01-05-CJ

LB15SKW01-05-CJ

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy LB15SKW01-05-CJ with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	LB15SKW01-05-CJ
Manufacturer	NKK Switches
Description	SWITCH PUSHBUTTON SPDT 3A 125V
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 7744 pcs
Reference Price (In US Dollars)	1 pcs
Reference Price (In US Dollars)	$4.557

Product parameter
Data sheet

Product parameter

Part Number	LB15SKW01-05-CJ	Manufacturer	NKK Switches
Description	SWITCH PUSHBUTTON SPDT 3A 125V	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	7744 pcs	Data sheet	LB Series Datasheet
Category	Switches	Voltage Rating - DC	30V
Voltage Rating - AC	125V	Type	Standard, Illuminated
Termination Style	Solder, Quick Connect - 0.110" (2.8mm)	Switch Function	On-Mom
Series	LB	Panel Cutout Dimensions	Square - 16.20mm²
Packaging	Bulk	Other Names	LB15SKW01-05-CJ-RO LB15SKW01-05-CJ-RO-ND
Operating Temperature	-25°C ~ 50°C	Mounting Type	Panel Mount, Snap-In
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Mechanical Life	1,000,000 Cycles
Manufacturer Standard Lead Time	13 Weeks	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Ingress Protection	-	Illumination Voltage (Nominal)	5 VAC
Illumination Type, Color	Incandescent, Red	Features	-
Electrical Life	100,000 Cycles	Detailed Description	Pushbutton Switch SPDT Standard, Illuminated Panel Mount, Snap-In
Current Rating	3A (AC/DC)	Color - Actuator/Cap	Red
Circuit	SPDT	Actuator Type	Square, Button
