PWR1546AC
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy PWR1546AC with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy PWR1546AC with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | PWR1546AC |
|---|---|
| Manufacturer | Murata Power Solutions |
| Description | DC DC CONVERTER +/-15V 5W |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 25 pcs | 50 pcs | 100 pcs | |
|---|---|---|---|---|---|
| $32.701 | $31.716 | $27.639 | $26.46 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | PWR1546AC | Manufacturer | Murata Power Solutions |
|---|---|---|---|
| Description | DC DC CONVERTER +/-15V 5W | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 1134 pcs | Data sheet | PWR1546AC |
| Category | Power Supplies - Board Mount | Voltage - Output 3 | - |
| Voltage - Output 2 | -15V | Voltage - Output 1 | 15V |
| Voltage - Isolation | 750V | Voltage - Input (Min) | 4.5V |
| Voltage - Input (Max) | 5.5V | Type | Isolated Module |
| Size / Dimension | 2.00" L x 2.00" W x 0.40" H (50.8mm x 50.8mm x 10.2mm) | Series | PWR1546AC |
| Power (Watts) | 5W | Packaging | Tube |
| Package / Case | 5-DIP Module | Other Names | 811-2690-5 |
| Operating Temperature | -25°C ~ 85°C | Number of Outputs | 2 |
| Mounting Type | Through Hole | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 30 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Features | SCP | Efficiency | 60% |
| Detailed Description | Isolated Module DC DC Converter 2 Output 15V -15V 167mA, 167mA 4.5V - 5.5V Input | Current - Output (Max) | 167mA, 167mA |
| Applications | ITE (Commercial) |
