NMS1209C
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy NMS1209C with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy NMS1209C with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | NMS1209C |
|---|---|
| Manufacturer | Murata Power Solutions |
| Description | DC DC CONVERTER +/-9V 2W |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 5 pcs | 10 pcs | 25 pcs | |
|---|---|---|---|---|---|
| $7.433 | $7.397 | $7.345 | $7.261 | ||
| 50 pcs | 100 pcs | 250 pcs | 500 pcs | ||
| $7.085 | $6.727 | $6.294 | $5.873 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | NMS1209C | Manufacturer | Murata Power Solutions |
|---|---|---|---|
| Description | DC DC CONVERTER +/-9V 2W | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 6175 pcs | Data sheet | NMS Series |
| Category | Power Supplies - Board Mount | Voltage - Output 3 | - |
| Voltage - Output 2 | -9V | Voltage - Output 1 | 9V |
| Voltage - Isolation | 6kV | Voltage - Input (Min) | 10.8V |
| Voltage - Input (Max) | 13.2V | Type | Isolated Module |
| Size / Dimension | 1.28" L x 0.58" W x 0.37" H (32.5mm x 14.7mm x 9.4mm) | Series | NMS |
| Power (Watts) | 2W | Packaging | Tube |
| Package / Case | 24-DIP Module (600 mil, 14 Leads) | Other Names | 811-1580-5 |
| Operating Temperature | 0°C ~ 70°C | Number of Outputs | 2 |
| Mounting Type | Through Hole | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 11 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Features | - | Efficiency | 81% |
| Detailed Description | Isolated Module DC DC Converter 2 Output 9V -9V 111mA, 111mA 10.8V - 13.2V Input | Current - Output (Max) | 111mA, 111mA |
| Applications | ITE (Commercial) |
