Home > Products > Power Supplies - Board Mount > DC DC Converters > NKA0305SC

NKA0305SC

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy NKA0305SC with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	NKA0305SC
Manufacturer	Murata Power Solutions
Description	DC DC CONVERTER +/-5V 1W
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

	100 pcs	250 pcs	500 pcs	1000 pcs
~~In Stock~~ 16075 pcs
Reference Price (In US Dollars)	1 pcs	5 pcs	10 pcs	25 pcs	50 pcs
	$2.721	$2.707	$2.689	$2.657	$2.592
	$2.464	$2.306	$2.149	$2.14

Product parameter
Data sheet

Product parameter

Part Number	NKA0305SC	Manufacturer	Murata Power Solutions
Description	DC DC CONVERTER +/-5V 1W	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	16075 pcs	Data sheet	NKA Series Datasheet
Category	Power Supplies - Board Mount	Voltage - Output 3	-
Voltage - Output 2	-5V	Voltage - Output 1	5V
Voltage - Isolation	3kV	Voltage - Input (Min)	3V
Voltage - Input (Max)	3.6V	Type	Isolated Module
Size / Dimension	0.65" L x 0.23" W x 0.30" H (16.5mm x 5.8mm x 7.6mm)	Series	NKA
Power (Watts)	1W	Packaging	Tube
Package / Case	6-SIP Module, 5 Leads	Other Names	811-1416-5
Operating Temperature	-40°C ~ 85°C	Number of Outputs	2
Mounting Type	Through Hole	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Manufacturer Standard Lead Time	18 Weeks	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Features	-	Efficiency	79%
Detailed Description	Isolated Module DC DC Converter 2 Output 5V -5V 100mA, 100mA 3V - 3.6V Input	Current - Output (Max)	100mA, 100mA
Control Features	-	Applications	ITE (Commercial)
