MAPC-104-C
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy MAPC-104-C with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy MAPC-104-C with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | MAPC-104-C |
|---|---|
| Manufacturer | Murata Power Solutions |
| Description | DC DC CNVRTR 3.3V 5.1V 12V 46W |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | Get a quote | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | MAPC-104-C | Manufacturer | Murata Power Solutions |
|---|---|---|---|
| Description | DC DC CNVRTR 3.3V 5.1V 12V 46W | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 5133 pcs | Data sheet | MAPC-104 PC,104 Plus Series |
| Category | Power Supplies - Board Mount | Voltage - Output 3 | 12V |
| Voltage - Output 2 | 5.1V | Voltage - Output 1 | 3.3V |
| Voltage - Input (Min) | 9V | Voltage - Input (Max) | 32V |
| Type | Non-Isolated PoL Module | Size / Dimension | 3.78" L x 3.55" W x 0.69" H (95.9mm x 90.2mm x 17.5mm) |
| Series | MAPC-104 | Power (Watts) | 46W |
| Packaging | Bulk | Package / Case | Module |
| Other Names | 811-2676 MAPC104C |
Operating Temperature | -40°C ~ 85°C |
| Number of Outputs | 3 | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Features | OCP, OTP, OVP, SCP, UVLO | Efficiency | 92.5% |
| Detailed Description | Non-Isolated PoL Module DC DC Converter 3 Output 3.3V 5.1V 12V 6A, 6.3A, 100mA 9V - 32V Input | Current - Output (Max) | 6A, 6.3A, 100mA |
| Applications | ITE (Commercial) |
