77209C
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 77209C with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 77209C with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 77209C |
|---|---|
| Manufacturer | Murata Power Solutions |
| Description | PULSE XFMR 2:1:1 16.3MH |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 25 pcs | ||||
|---|---|---|---|---|---|
| $2.426 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | 77209C | Manufacturer | Murata Power Solutions |
|---|---|---|---|
| Description | PULSE XFMR 2:1:1 16.3MH | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 14766 pcs | Data sheet | 772 Series Datasheet |
| Category | Transformers | Weight | - |
| Turns Ratio - Primary:Secondary | 2:1:1 | Transformer Type | SCR and Triac Trigger (Encapsulated) |
| Size / Dimension | 1.000" L x 0.799" W (25.40mm x 20.30mm) | Series | * |
| Packaging | Tube | Operating Temperature | 0°C ~ 70°C |
| Mounting Type | Through Hole | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 13 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Inductance | 16.3mH | Height - Seated (Max) | 0.484" (12.30mm) |
| Energy Time (E.T.) | 482V µS |
