56300C
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 56300C with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 56300C with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 56300C |
|---|---|
| Manufacturer | Murata Power Solutions |
| Description | CURR SENSE XFMR 10A T/H |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $0.594 | $0.586 | $0.579 | $0.561 | ||
| 100 pcs | 250 pcs | 500 pcs | |||
| $0.539 | $0.502 | $0.468 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | 56300C | Manufacturer | Murata Power Solutions |
|---|---|---|---|
| Description | CURR SENSE XFMR 10A T/H | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 77956 pcs | Data sheet | 5600 Series |
| Category | Transformers | Weight | 0.013 lb (5.70g) |
| Type | Non-Invasive (Solid Core) | Turns Ratio - Primary:Secondary | - |
| Termination Style | PC Pin | Size / Dimension | 0.661" L x 0.350" W (16.79mm x 8.89mm) |
| Series | 5600 | Ratings | - |
| Packaging | Tube | Other Names | 56300C-ND 811-3110 |
| Mounting Type | Through Hole | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 9 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Height - Seated (Max) | 0.795" (20.19mm) | Frequency Range | 20kHz ~ 200kHz |
| Energy Time (E.T.) | - | Detailed Description | 10A Current Sense Transformer 20kHz ~ 200kHz 5.73 mOhm Primary, 8.59 mOhm Secondary Through Hole |
| DC Resistance (DCR) | 5.73 mOhm Primary, 8.59 mOhm Secondary | Current Ratio | 300:1 |
| Current Rating | 10A |
