55200C
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 55200C with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 55200C with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 55200C |
|---|---|
| Manufacturer | Murata Power Solutions |
| Description | CURR SENSE XFMR 1:1:200 15A SMD |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 5 pcs | 10 pcs | 25 pcs | |
|---|---|---|---|---|---|
| $1.244 | $1.196 | $1.148 | $1.034 | ||
| 50 pcs | 100 pcs | 250 pcs | |||
| $0.888 | $0.811 | $0.715 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | 55200C | Manufacturer | Murata Power Solutions |
|---|---|---|---|
| Description | CURR SENSE XFMR 1:1:200 15A SMD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 53371 pcs | Data sheet | 5500 Series |
| Category | Transformers | Weight | 0.06 oz (1.71g) |
| Type | Invasive | Turns Ratio - Primary:Secondary | 1:1:200 |
| Termination Style | - | Size / Dimension | 0.496" L x 0.575" W (12.60mm x 14.60mm) |
| Series | 5500 | Ratings | - |
| Packaging | Tube | Other Names | 811-1202-5 |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Inductance | 60mH |
| Height - Seated (Max) | 0.280" (7.10mm) | Frequency Range | 50kHz ~ 500kHz |
| Energy Time (E.T.) | - | Detailed Description | 1:1:200 Current Sense Transformer 50kHz ~ 500kHz 2.3 mOhm Primary, 3.6 Ohm Secondary 60mH Surface Mount |
| DC Resistance (DCR) | 2.3 mOhm Primary, 3.6 Ohm Secondary | Current Ratio | - |
