32220C
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 32220C with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 32220C with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 32220C |
|---|---|
| Manufacturer | Murata Power Solutions |
| Description | FIXED IND 22UH 3A 29 MOHM TH |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 5 pcs | 10 pcs | 25 pcs | |
|---|---|---|---|---|---|
| $0.626 | $0.611 | $0.59 | $0.561 | ||
| 50 pcs | 100 pcs | 250 pcs | 500 pcs | ||
| $0.525 | $0.504 | $0.49 | $0.485 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 32220C | Manufacturer | Murata Power Solutions |
|---|---|---|---|
| Description | FIXED IND 22UH 3A 29 MOHM TH | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 79845 pcs | Data sheet | 3200 Series |
| Category | Inductors, Coils, Chokes | Type | Toroidal |
| Tolerance | ±15% | Supplier Device Package | - |
| Size / Dimension | 0.846" L x 0.394" W (21.50mm x 10.00mm) | Shielding | Unshielded |
| Series | 3200 | Ratings | - |
| Q @ Freq | 3.2 @ 1MHz | Packaging | Tray |
| Package / Case | Radial | Other Names | 811-1220 |
| Operating Temperature | -40°C ~ 125°C | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material - Core | - |
| Manufacturer Standard Lead Time | 10 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Inductance Frequency - Test | 1MHz | Inductance | 22µH |
| Height - Seated (Max) | 0.945" (24.00mm) | Frequency - Self Resonant | 41MHz |
| Detailed Description | 22µH Unshielded Toroidal Inductor 3A 29 mOhm Max Radial | DC Resistance (DCR) | 29 mOhm Max |
| Current Rating | 3A | Current - Saturation | - |
