PLT10HH101150PNL
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy PLT10HH101150PNL with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy PLT10HH101150PNL with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | PLT10HH101150PNL |
|---|---|
| Manufacturer | Murata Electronics |
| Description | CMC 15A 2LN 100 OHM SMD AEC-Q200 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 125 pcs | 250 pcs | 625 pcs | 1250 pcs | |
|---|---|---|---|---|---|
| $2.769 | $2.509 | $2.423 | $2.336 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | PLT10HH101150PNL | Manufacturer | Murata Electronics |
|---|---|---|---|
| Description | CMC 15A 2LN 100 OHM SMD AEC-Q200 | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 13263 pcs | Data sheet | PLT10HHyyyyyyPNy Spec |
| Category | Filters | Voltage Rating - DC | 300V |
| Voltage Rating - AC | - | Size / Dimension | 0.508" L x 0.358" W (12.90mm x 9.10mm) |
| Series | PLT10H | Ratings | AEC-Q200 |
| Packaging | Tape & Reel (TR) | Package / Case | Vertical, 4 PC Pad |
| Other Names | 490-12821-2 | Operating Temperature | -55°C ~ 125°C |
| Number of Lines | 2 | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 10 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Impedance @ Frequency | 100 Ohms @ 10MHz |
| Height (Max) | 0.370" (9.40mm) | Filter Type | Power Line |
| Features | - | Detailed Description | 2 Line Common Mode Choke Surface Mount 100 Ohms @ 10MHz 15A DCR 2.3 mOhm |
| DC Resistance (DCR) (Max) | 2.3 mOhm | Current Rating (Max) | 15A |
| Approvals | - |
