LQW2BAN24NJ00L
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy LQW2BAN24NJ00L with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy LQW2BAN24NJ00L with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | LQW2BAN24NJ00L |
|---|---|
| Manufacturer | Murata Electronics |
| Description | FIXED IND 24NH 1.4A 150 MOHM |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 2000 pcs | 4000 pcs | 6000 pcs | 10000 pcs | 50000 pcs |
|---|---|---|---|---|---|
| $0.07 | $0.066 | $0.064 | $0.061 | $0.057 | |
- Product parameter
- Data sheet
Product parameter
| Part Number | LQW2BAN24NJ00L | Manufacturer | Murata Electronics |
|---|---|---|---|
| Description | FIXED IND 24NH 1.4A 150 MOHM | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 369925 pcs | Data sheet | RF Inductor Part NumberingChip Inductors CatalogLQW2BANyyyy00L Series Spec |
| Category | Inductors, Coils, Chokes | Type | Wirewound |
| Tolerance | ±5% | Supplier Device Package | - |
| Size / Dimension | 0.082" L x 0.060" W (2.09mm x 1.53mm) | Shielding | Unshielded |
| Series | LQW2 | Ratings | - |
| Q @ Freq | 78 @ 500MHz | Packaging | Tape & Reel (TR) |
| Package / Case | 0805 (2015 Metric) | Other Names | 490-16030-2 |
| Operating Temperature | -55°C ~ 125°C | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material - Core | Non-Magnetic |
| Manufacturer Standard Lead Time | 9 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Inductance Frequency - Test | 250MHz | Inductance | 24nH |
| Height - Seated (Max) | 0.060" (1.52mm) | Frequency - Self Resonant | 1.97GHz |
| Detailed Description | 24nH Unshielded Wirewound Inductor 1.4A 150 mOhm Max 0805 (2015 Metric) | DC Resistance (DCR) | 150 mOhm Max |
| Current Rating | 1.4A | Current - Saturation | - |
