Home > Products > Kits > EMI, Filter Kits > EKDMGN03-KIT

EKDMGN03-KIT

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy EKDMGN03-KIT with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	EKDMGN03-KIT
Manufacturer	Murata Electronics
Description	KIT COMMON MODE CHOKE
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 1084 pcs
Reference Price (In US Dollars)	1 pcs	10 pcs	25 pcs	50 pcs	100 pcs
Reference Price (In US Dollars)	$40.356	$39.01	$37.665	$36.32	$34.975

Product parameter
Data sheet

Product parameter

Part Number	EKDMGN03-KIT	Manufacturer	Murata Electronics
Description	KIT COMMON MODE CHOKE	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	1084 pcs	Data sheet	DLW21HNyyyHQ2y Spec DLW21SNyyyXQ2y Spec DLM11SNyyyHY2y Spec DLP0NSyyyHL2y Spec
Category	Kits	Series	DLM, DLP, DLW
Quantity	540 Pieces (54 Values - 10 Each)	Packages Included	0202, 0302, 0504, 0603, 0804
Other Names	490-17336 EKDMGN03-KIT-ND	Mounting Type	Surface Mount
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Manufacturer Standard Lead Time	11 Weeks
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Kit Type	Common Mode Chokes for Signal Lines
Features	-	Detailed Description	Common Mode Chokes for Signal Lines Kit 540 Pieces (54 Values - 10 Each) Surface Mount
