BNX003-01
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy BNX003-01 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy BNX003-01 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | BNX003-01 |
|---|---|
| Manufacturer | Murata Electronics |
| Description | FILTER LC TH |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $3.103 | $2.644 | $2.052 | $1.954 | ||
| 100 pcs | 250 pcs | 500 pcs | 1000 pcs | ||
| $1.839 | $1.667 | $1.609 | $1.552 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | BNX003-01 | Manufacturer | Murata Electronics |
|---|---|---|---|
| Description | FILTER LC TH | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 25476 pcs | Data sheet | EMI Suppression Filters CatalogBNX003-01 Spec |
| Category | Filters | Voltage - Rated | 150V |
| Values | - | Type | Low Pass |
| Technology | LC | Size / Dimension | 0.472" L x 0.433" W (12.00mm x 11.00mm) |
| Series | EMIFIL®, BNX | Resistance - Channel (Ohms) | - |
| Packaging | Bulk | Package / Case | Block, 4 Lead |
| Other Names | 490-12627 BNX003-01-ND |
Operating Temperature | -30°C ~ 85°C |
| Number of Channels | 2 | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 7 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Height | 0.512" (13.00mm) |
| Filter Order | 5th | ESD Protection | No |
| Detailed Description | LC EMI Filter 5th Order Low Pass 2 Channel 10A Block, 4 Lead | Current | 10A |
| Center / Cutoff Frequency | - | Attenuation Value | 40dB @ 5MHz ~ 1GHz |
| Applications | Data Lines for Mobile Devices |
