760871131
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 760871131 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 760871131 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 760871131 |
|---|---|
| Manufacturer | Midcom / Wurth Electronics |
| Description | OFFLINE XFRM WE-UNIT ST VIPER26 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 50 pcs | 100 pcs | 500 pcs |
|---|---|---|---|---|---|
| $2.878 | $2.84 | $2.663 | $2.397 | $2.13 | |
- Product parameter
- Data sheet
Product parameter
| Part Number | 760871131 | Manufacturer | Midcom / Wurth Electronics |
|---|---|---|---|
| Description | OFFLINE XFRM WE-UNIT ST VIPER26 | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 18439 pcs | Data sheet | 760871131 |
| Category | Transformers | Voltage - Primary | 120 ~ 420V |
| Voltage - Isolation | 4000Vrms | Voltage - Auxiliary | 15V @ 100mA |
| Type | For AC/DC Converters | Size / Dimension | 0.874" L x 0.984" W (22.20mm x 25.00mm) |
| Series | WE-UNIT, MID-OLSTM | Packaging | Tray |
| Other Names | 1297-1063 | Operating Temperature | -40°C ~ 125°C |
| Mounting Type | Through Hole | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 18 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Intended Chipset | - | Inductance @ Frequency | 1.396mH @ 10kHz |
| Height - Seated (Max) | 0.635" (16.13mm) | Frequency | 60kHz |
| Footprint | 0.874" L x 0.984" W (22.20mm x 25.00mm) | Chipset Manufacturer | STMicroelectronics |
| Applications | LED Drivers, AC/DC SMPS |
