750343109
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 750343109 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 750343109 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 750343109 |
|---|---|
| Manufacturer | Midcom / Wurth Electronics |
| Description | XFRMER FLYBACK AC/DC CONV TH |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 50 pcs | 70 pcs | 140 pcs |
|---|---|---|---|---|---|
| $2.737 | $2.60 | $2.462 | $2.324 | $2.19 | |
- Product parameter
- Data sheet
Product parameter
| Part Number | 750343109 | Manufacturer | Midcom / Wurth Electronics |
|---|---|---|---|
| Description | XFRMER FLYBACK AC/DC CONV TH | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 16050 pcs | Data sheet | 750343109 Drawing |
| Category | Transformers | Voltage - Primary | 90 ~ 264V |
| Voltage - Isolation | 3000Vrms | Voltage - Auxiliary | 14V |
| Type | For AC/DC Converters | Size / Dimension | 0.874" L x 1.024" W (22.20mm x 26.00mm) |
| Series | WE-FB, MID-OLDIA | Other Names | 1297-1188 |
| Operating Temperature | -40°C ~ 125°C | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 14 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Intended Chipset | - |
| Inductance @ Frequency | 490µH @ 10kHz | Height - Seated (Max) | 0.635" (16.13mm) |
| Frequency | 70kHz | Footprint | 0.874" L x 1.024" W (22.20mm x 26.00mm) |
| Chipset Manufacturer | Dialog Semiconductor | Applications | Flyback Converters |
