Home > Products > Transformers > Switching Converter, SMPS Transformers > 750341086

750341086

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 750341086 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	750341086
Manufacturer	Midcom / Wurth Electronics
Description	PWR XFRM LM3440
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 19185 pcs
Reference Price (In US Dollars)	90 pcs
Reference Price (In US Dollars)	$1.709

Product parameter
Data sheet

Product parameter

Part Number	750341086	Manufacturer	Midcom / Wurth Electronics
Description	PWR XFRM LM3440	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	19185 pcs	Data sheet	750341086 Drawing
Category	Transformers	Voltage - Primary	85 ~ 135V
Voltage - Isolation	4500Vrms	Voltage - Auxiliary	22V @ 10mA
Type	For AC/DC Converters	Size / Dimension	0.665" L x 0.740" W (16.90mm x 18.80mm)
Series	MID-OLTI	Packaging	Tray
Other Names	1297-1026	Operating Temperature	-40°C ~ 125°C
Mounting Type	Through Hole	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Manufacturer Standard Lead Time	14 Weeks	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Intended Chipset	-	Inductance @ Frequency	850µH @ 10kHz
Height - Seated (Max)	0.529" (13.44mm)	Frequency	100kHz
Footprint	0.665" L x 0.740" W (16.90mm x 18.80mm)	Chipset Manufacturer	-
Applications	LED Drivers, AC/DC SMPS
