Home > Products > Transformers > Switching Converter, SMPS Transformers > 750315882

750315882

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 750315882 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	750315882
Manufacturer	Midcom / Wurth Electronics
Description	FLYBACK TRANSFORMER WE-FB
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 22173 pcs
Reference Price (In US Dollars)	250 pcs
Reference Price (In US Dollars)	$1.418

Product parameter
Data sheet

Product parameter

Part Number	750315882	Manufacturer	Midcom / Wurth Electronics
Description	FLYBACK TRANSFORMER WE-FB	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	22173 pcs	Data sheet	750315882 Drawing
Category	Transformers	Voltage - Primary	17 ~ 36V
Voltage - Isolation	1875Vrms	Voltage - Auxiliary	-
Type	For DC/DC Converters	Style	-
Series	*	Packaging	Tape & Reel (TR)
Other Names	1297-1235-2	Operating Temperature	-40°C ~ 125°C
Mounting Type	Surface Mount	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Manufacturer Standard Lead Time	14 Weeks	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Intended Chipset	-	Height - Seated (Max)	-
Frequency	500kHz	Chipset Manufacturer	Maxim Integrated
Applications	Flyback Converters
