750315240
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 750315240 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 750315240 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 750315240 |
|---|---|
| Manufacturer | Midcom / Wurth Electronics |
| Description | XFRMR FWD P-P DC/DC CONV SMD |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 275 pcs | 550 pcs | |||
|---|---|---|---|---|---|
| $0.855 | $0.748 | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | 750315240 | Manufacturer | Midcom / Wurth Electronics |
|---|---|---|---|
| Description | XFRMR FWD P-P DC/DC CONV SMD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 39755 pcs | Data sheet | 750315240 Drawing |
| Category | Transformers | Voltage - Primary | - |
| Voltage - Isolation | 5000Vrms | Voltage - Auxiliary | - |
| Type | For DC/DC Converters | Size / Dimension | 0.485" L x 0.410" W (12.32mm x 10.41mm) |
| Series | WE-PP, MID-PPTI | Packaging | Tape & Reel (TR) |
| Other Names | 1297-1177-2 | Operating Temperature | -40°C ~ 125°C |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 14 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Intended Chipset | SN6505A | Inductance @ Frequency | 110µH @ 100kHz |
| Height - Seated (Max) | 0.440" (11.18mm) | Frequency | 150kHz |
| Footprint | 0.485" L x 0.607" W (12.32mm x 15.41mm) | Chipset Manufacturer | Texas Instruments |
| Applications | Forward, Push-Pull Converters |
