SG109T-JAN
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy SG109T-JAN with confidence from Components-World.HK, 1 Year Warranty
Dowload SG109T-JAN Details in PDFSee Product Specifications for product details.
Buy SG109T-JAN with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | SG109T-JAN |
|---|---|
| Manufacturer | Microsemi |
| Description | IC REG LINEAR 5.05V 1A TO39 |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Reference Price (In US Dollars) | Get a quote | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | SG109T-JAN | Manufacturer | Microsemi |
|---|---|---|---|
| Description | IC REG LINEAR 5.05V 1A TO39 | Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Quantity Available | 5439 pcs | Data sheet | SG109/SG309 |
| Category | Integrated Circuits (ICs) | Voltage Dropout (Max) | - |
| Voltage - Output (Min/Fixed) | 5.05V | Voltage - Output (Max) | - |
| Voltage - Input (Max) | 25V | Supplier Device Package | TO-39 |
| Series | Military, MIL-STD-883 | Protection Features | Over Temperature |
| Packaging | Bulk | Package / Case | TO-205AD, TO-39-3 Metal Can |
| PSRR | - | Output Type | Fixed |
| Output Configuration | Positive | Other Names | 1259-1165 1259-1165-MIL M38510/10701BXA Q11244981 Q12118148 |
| Operating Temperature | -55°C ~ 125°C | Number of Regulators | 1 |
| Mounting Type | Through Hole | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | Detailed Description | Linear Voltage Regulator IC Positive Fixed 1 Output 5.09V 1A TO-39 |
| Current - Quiescent (Iq) | 10mA | Current - Output | 1A |
| Control Features | - |
