Home > Products > Discrete Semiconductor Products > Diodes - Rectifiers - Single > MC5616

MC5616

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy MC5616 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	MC5616
Manufacturer	Microsemi
Description	DIODE GEN PURP 3KV 570MA S AXIAL
Lead Free Status / RoHS Status	Contains lead / RoHS non-compliant

~~In Stock~~ 981 pcs
Reference Price (In US Dollars)	1 pcs	10 pcs
Reference Price (In US Dollars)	$33.837	$31.721

Product parameter
Data sheet

Product parameter

Part Number	MC5616	Manufacturer	Microsemi
Description	DIODE GEN PURP 3KV 570MA S AXIAL	Lead Free Status / RoHS Status	Contains lead / RoHS non-compliant
Quantity Available	981 pcs	Data sheet	MC5610 - 5619
Category	Discrete Semiconductor Products	Voltage - Forward (Vf) (Max) @ If	6V @ 100mA
Voltage - DC Reverse (Vr) (Max)	3000V	Supplier Device Package	S, Axial
Speed	Fast Recovery = 200mA (Io)	Series	-
Reverse Recovery Time (trr)	300ns	Packaging	Bulk
Package / Case	S, Axial	Other Names	1086-15610 1086-15610-MIL
Operating Temperature - Junction	-65°C ~ 150°C	Mounting Type	Through Hole
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Lead Free Status / RoHS Status	Contains lead / RoHS non-compliant
Diode Type	Standard	Detailed Description	Diode Standard 3000V 570mA Through Hole S, Axial
Current - Reverse Leakage @ Vr	1µA @ 3000V	Current - Average Rectified (Io)	570mA
Capacitance @ Vr, F	-
