LX8816-04CDF
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy LX8816-04CDF with confidence from Components-World.HK, 1 Year Warranty
Dowload LX8816-04CDF Details in PDFSee Product Specifications for product details.
Buy LX8816-04CDF with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | LX8816-04CDF |
|---|---|
| Manufacturer | Microsemi |
| Description | IC REG LIN POS ADJ 1A/1A 5SPAK |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | Get a quote | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | LX8816-04CDF | Manufacturer | Microsemi |
|---|---|---|---|
| Description | IC REG LIN POS ADJ 1A/1A 5SPAK | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 4480 pcs | Data sheet | LX8816 |
| Category | Integrated Circuits (ICs) | Voltage Dropout (Max) | 1.3V @ 1A, 1.3V @ 1A |
| Voltage - Output (Min/Fixed) | 1.25V (3.3V) | Voltage - Output (Max) | 5.5V |
| Voltage - Input (Max) | 10V | Supplier Device Package | 5-SPAK |
| Series | - | Protection Features | Over Current, Over Temperature |
| Packaging | Bulk | Package / Case | SPak-5 (5 leads + Tab) |
| PSRR | 75dB (120Hz) | Output Type | Adjustable (Fixed) |
| Output Configuration | Positive | Operating Temperature | 0°C ~ 125°C |
| Number of Regulators | 2 | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Detailed Description | Linear Voltage Regulator IC Positive Fixed and Adjustable 2 Output 3.3V, 1.2 V ~ 5.5 V 1A, 1A 5-SPAK | Current - Supply (Max) | 6A |
| Current - Quiescent (Iq) | 3.8mA | Current - Output | 1A, 1A |
| Control Features | - | Base Part Number | LX8816 |
