APTGF50TL60T3G
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy APTGF50TL60T3G with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy APTGF50TL60T3G with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | APTGF50TL60T3G |
|---|---|
| Manufacturer | Microsemi |
| Description | IGBT ARRAY 600V 65A 250W SP3 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | Get a quote | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | APTGF50TL60T3G | Manufacturer | Microsemi |
|---|---|---|---|
| Description | IGBT ARRAY 600V 65A 250W SP3 | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 4555 pcs | Data sheet | Power Products CatalogSolar Solutions |
| Category | Discrete Semiconductor Products | Voltage - Collector Emitter Breakdown (Max) | 600V |
| Vce(on) (Max) @ Vge, Ic | 2.45V @ 15V, 50A | Supplier Device Package | SP3 |
| Series | - | Power - Max | 250W |
| Package / Case | SP3 | Other Names | APTGF50TL60T3GMP APTGF50TL60T3GMP-ND |
| Operating Temperature | -55°C ~ 150°C (TJ) | NTC Thermistor | Yes |
| Mounting Type | Chassis Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Input Capacitance (Cies) @ Vce | 2.2nF @ 25V |
| Input | Standard | IGBT Type | NPT |
| Detailed Description | IGBT Module NPT Three Level Inverter 600V 65A 250W Chassis Mount SP3 | Current - Collector Cutoff (Max) | 250µA |
| Current - Collector (Ic) (Max) | 65A | Configuration | Three Level Inverter |
