MCM1206-TP
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy MCM1206-TP with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy MCM1206-TP with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | MCM1206-TP |
|---|---|
| Manufacturer | Micro Commercial Components (MCC) |
| Description | MOSFET P-CH 12V 6A DFN202 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 3000 pcs | ||||
|---|---|---|---|---|---|
| $0.056 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | MCM1206-TP | Manufacturer | Micro Commercial Components (MCC) |
|---|---|---|---|
| Description | MOSFET P-CH 12V 6A DFN202 | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 403850 pcs | Data sheet | MCM1206 |
| Category | Discrete Semiconductor Products | Vgs(th) (Max) @ Id | 0.9V @ 250µA |
| Vgs (Max) | ±8V | Technology | MOSFET (Metal Oxide) |
| Supplier Device Package | DFN2020-6J | Series | - |
| Rds On (Max) @ Id, Vgs | 45 mOhm @ 3.5A, 4.5V | Power Dissipation (Max) | - |
| Packaging | Tape & Reel (TR) | Package / Case | 6-WDFN Exposed Pad |
| Other Names | MCM1206-TPMSTR | Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 22 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Input Capacitance (Ciss) (Max) @ Vds | 740pF @ 4V | Gate Charge (Qg) (Max) @ Vgs | 7.8nC @ 4.5V |
| FET Type | P-Channel | FET Feature | - |
| Drive Voltage (Max Rds On, Min Rds On) | 1.8V, 4.5V | Drain to Source Voltage (Vdss) | 12V |
| Detailed Description | P-Channel 12V 6A (Ta) Surface Mount DFN2020-6J | Current - Continuous Drain (Id) @ 25°C | 6A (Ta) |
