Home > Products > Development Boards, Kits, Programmers > Evaluation and Demonstration Boards and Kits > MCP215XDM

MCP215XDM

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy MCP215XDM with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	MCP215XDM
Manufacturer	Micrel / Microchip Technology
Description	BOARD DEMO FOR MCP215X
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 4620 pcs
Reference Price (In US Dollars)	Get a quote

Product parameter
Data sheet

Product parameter

Part Number	MCP215XDM	Manufacturer	Micrel / Microchip Technology
Description	BOARD DEMO FOR MCP215X	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	4620 pcs	Data sheet	MCP215X Data Logger Demo Board Users Guide
Category	Development Boards, Kits, Programmers	Utilized IC / Part	MCP2150, MCP2155
Type	Interface	Supplied Contents	Board(s), Power Supply
Series	-	Secondary Attributes	Set up as a Data Logger with LCD, GUI, Socket for EEPROM, Battery Powerable
Primary Attributes	IrDA Controller with PIC18F MCU	Other Names	MCP215XDMR MCP215XDMR-ND
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Function	IrDA	Embedded	Yes, MCU, 8-Bit
Detailed Description	MCP2150, MCP2155 IrDA Interface Evaluation Board
