Home > Products > Development Boards, Kits, Programmers > Evaluation Boards - DC/DC & AC/DC (Off-Line) S > MCP1650DM-DDSC1

MCP1650DM-DDSC1

MCP1650DM-DDSC1

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy MCP1650DM-DDSC1 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	MCP1650DM-DDSC1
Manufacturer	Micrel / Microchip Technology
Description	BOARD DEMO FOR MCP1650 SEPIC
Lead Free Status / RoHS Status	Contains lead / RoHS non-compliant

~~In Stock~~ 5209 pcs
Reference Price (In US Dollars)	7 pcs
Reference Price (In US Dollars)	$7.407

Product parameter
Data sheet

Product parameter

Part Number	MCP1650DM-DDSC1	Manufacturer	Micrel / Microchip Technology
Description	BOARD DEMO FOR MCP1650 SEPIC	Lead Free Status / RoHS Status	Contains lead / RoHS non-compliant
Quantity Available	5209 pcs	Data sheet	MCP1650 SEPIC Demo Board Guide MCP1650-53
Category	Development Boards, Kits, Programmers	Voltage - Output	5V
Voltage - Input	3 V ~ 7 V	Utilized IC / Part	MCP1650
Supplied Contents	Board(s)	Series	-
Regulator Topology	Boost	Outputs and Type	1, Non-Isolated
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Main Purpose	DC/DC, Step Up or Down
Lead Free Status / RoHS Status	Contains lead / RoHS non-compliant	Frequency - Switching	750kHz
Detailed Description	MCP1650 - DC/DC, Step Up or Down 1, Non-Isolated Outputs Evaluation Board	Current - Output	160mA
Board Type	Fully Populated
