Home > Products > Development Boards, Kits, Programmers > Evaluation and Demonstration Boards and Kits > MCP1631RD-MCC2

MCP1631RD-MCC2

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy MCP1631RD-MCC2 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	MCP1631RD-MCC2
Manufacturer	Micrel / Microchip Technology
Description	REFERENCE DESIGN MCP1631HV
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 2213 pcs
Reference Price (In US Dollars)	1 pcs
Reference Price (In US Dollars)	$15.005

Product parameter
Data sheet

Product parameter

Part Number	MCP1631RD-MCC2	Manufacturer	Micrel / Microchip Technology
Description	REFERENCE DESIGN MCP1631HV	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	2213 pcs	Data sheet	Portable Power Conversion Design Guide PIC16F882-84/86-87 MCP1631(HV,V,VHV)MCP1631HV Battery Charger RD
Category	Development Boards, Kits, Programmers	Utilized IC / Part	MCP1631HV, PIC16F883
Type	Power Management	Supplied Contents	Board(s)
Series	-	Secondary Attributes	On-Board LEDs
Primary Attributes	1 ~ 2 Cell- Li-Ion, 1 ~ 5 Cell- NiCd/NiMH, 1 ~ 2 1W LEDs	Other Names	MCP1631RDMCC2
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Function	Battery Charger	Embedded	Yes, MCU, 8-Bit
Detailed Description	MCP1631HV, PIC16F883 Battery Charger Power Management Evaluation Board
