Home > Products > RF/IF and RFID > RF Transceiver Modules > ATZB-S1-256-3-0-U

ATZB-S1-256-3-0-U

ATZB-S1-256-3-0-U

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy ATZB-S1-256-3-0-U with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	ATZB-S1-256-3-0-U
Manufacturer	Micrel / Microchip Technology
Description	RF TXRX MODULE 802.15.4 U.FL ANT
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 4526 pcs
Reference Price (In US Dollars)	Get a quote

Product parameter
Data sheet

Product parameter

Part Number	ATZB-S1-256-3-0-U	Manufacturer	Micrel / Microchip Technology
Description	RF TXRX MODULE 802.15.4 U.FL ANT	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	4526 pcs	Data sheet	ATZB-S1-256-3-0-U(F)
Category	RF/IF and RFID	Voltage - Supply	1.8 V ~ 3.6 V
Utilized IC / Part	-	Series	ZigBit™
Serial Interfaces	ISP, JTAG, SPI, UART, USART	Sensitivity	-97dBm
RF Family/Standard	802.15.4	Protocol	Zigbee®
Power - Output	3.5dBm	Packaging	Bulk
Package / Case	Module	Operating Temperature	-40°C ~ 85°C
Mounting Type	Surface Mount	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Modulation	-	Memory Size	256kB Flash, 8kB EEPROM, 32kB SRAM
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Frequency	2.4GHz
Data Rate	2Mbps	Current - Transmitting	9.9mA ~ 16.3mA
Current - Receiving	17mA	Antenna Type	Not Included, U.FL
