ADM00566
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy ADM00566 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy ADM00566 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | ADM00566 |
|---|---|
| Manufacturer | Micrel / Microchip Technology |
| Description | MCP1661 EVAL BOARD |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | ||||
|---|---|---|---|---|---|
| $14.576 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | ADM00566 | Manufacturer | Micrel / Microchip Technology |
|---|---|---|---|
| Description | MCP1661 EVAL BOARD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 2196 pcs | Data sheet | MCP1661MCP1661 Eval Brd Guide |
| Category | Development Boards, Kits, Programmers | Voltage - Output | 3.3V, 12V |
| Voltage - Input | 2.4 V ~ 5.5 V | Utilized IC / Part | MCP1661 |
| Supplied Contents | Board(s) | Series | - |
| Regulator Topology | Boost, SEPIC | Outputs and Type | 2, Non-Isolated |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Main Purpose | DC/DC, Step Up |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Frequency - Switching | 500kHz |
| Detailed Description | MCP1661 - DC/DC, Step Up 2, Non-Isolated Outputs Evaluation Board | Current - Output | 125mA |
| Board Type | Fully Populated |
