ADM00399
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy ADM00399 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy ADM00399 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | ADM00399 |
|---|---|
| Manufacturer | Micrel / Microchip Technology |
| Description | BOARD DEMO BUCK BOOST MCP16301 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | ||||
|---|---|---|---|---|---|
| $12.099 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | ADM00399 | Manufacturer | Micrel / Microchip Technology |
|---|---|---|---|
| Description | BOARD DEMO BUCK BOOST MCP16301 | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 2622 pcs | Data sheet | MCP16301/H DatasheetPortable Power Conversion Design GuideMCP16301 User Guide |
| Category | Development Boards, Kits, Programmers | Voltage - Output | 12V |
| Voltage - Input | 5 V ~ 30 V | Utilized IC / Part | MCP16301 |
| Supplied Contents | Board(s) | Series | - |
| Regulator Topology | Buck-Boost | Outputs and Type | 1, Non-Isolated |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Main Purpose | DC/DC, Step Up or Down |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Frequency - Switching | 500kHz |
| Detailed Description | MCP16301 - DC/DC, Step Up or Down 1, Non-Isolated Outputs Evaluation Board | Current - Output | - |
| Board Type | Fully Populated |
