Home > Products > Integrated Circuits (ICs) > Data Acquisition - Digital to Analog Converters (D > MX7520UQ/883B

MX7520UQ/883B

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy MX7520UQ/883B with confidence from Components-World.HK, 1 Year Warranty

Dowload MX7520UQ/883B Details in PDF

Request a Quote

Part Number	MX7520UQ/883B
Manufacturer	Maxim Integrated
Description	IC DAC COTS
Lead Free Status / RoHS Status	Contains lead / RoHS non-compliant

~~In Stock~~ 5144 pcs
Reference Price (In US Dollars)	Get a quote

Product parameter
Data sheet

Product parameter

Part Number	MX7520UQ/883B	Manufacturer	Maxim Integrated
Description	IC DAC COTS	Lead Free Status / RoHS Status	Contains lead / RoHS non-compliant
Quantity Available	5144 pcs	Data sheet	MX7520x(x)/883B MX7520,21
Category	Integrated Circuits (ICs)	Voltage - Supply, Digital	5 V ~ 15 V
Voltage - Supply, Analog	5 V ~ 15 V	Supplier Device Package	16-CDIP
Settling Time	500µs (Typ)	Series	-
Reference Type	External	Packaging	Tube
Package / Case	16-CDIP (0.300", 7.62mm)	Output Type	Current - Unbuffered
Operating Temperature	-55°C ~ 125°C	Number of D/A Converters	1
Number of Bits	10	Mounting Type	Through Hole
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Lead Free Status / RoHS Status	Contains lead / RoHS non-compliant
INL/DNL (LSB)	-	Differential Output	Yes
Detailed Description	10 Bit Digital to Analog Converter 1 16-CDIP	Data Interface	Parallel
Architecture	R-2R
