Home > Products > Development Boards, Kits, Programmers > Evaluation Boards - DC/DC & AC/DC (Off-Line) S > MAX5022EVKIT

MAX5022EVKIT

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy MAX5022EVKIT with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	MAX5022EVKIT
Manufacturer	Maxim Integrated
Description	EVAL KIT FOR MAX5022
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 1665 pcs
Reference Price (In US Dollars)	1 pcs
Reference Price (In US Dollars)	$20.971

Product parameter
Data sheet

Product parameter

Part Number	MAX5022EVKIT	Manufacturer	Maxim Integrated
Description	EVAL KIT FOR MAX5022	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	1665 pcs	Data sheet	MAX5021/22 MAX5022 Eval Kit
Category	Development Boards, Kits, Programmers	Voltage - Output	5V
Voltage - Input	85 ~ 265 VAC	Utilized IC / Part	MAX5022
Supplied Contents	Board(s)	Series	-
Regulator Topology	Flyback	Power - Output	5W
Outputs and Type	1, Isolated	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Manufacturer Standard Lead Time	6 Weeks	Main Purpose	AC/DC, Primary Side
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Frequency - Switching	262kHz
Detailed Description	MAX5022 - AC/DC, Primary Side 1, Isolated Outputs Evaluation Board	Current - Output	1A
Board Type	Fully Populated
