RD-3513
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy RD-3513 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy RD-3513 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | RD-3513 |
|---|---|
| Manufacturer | MEAN WELL |
| Description | AC/DC CONVERTER +/-13.5V 35W |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $6.065 | $5.893 | $5.546 | $5.373 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | RD-3513 | Manufacturer | MEAN WELL |
|---|---|---|---|
| Description | AC/DC CONVERTER +/-13.5V 35W | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 5738 pcs | Data sheet | RD-35 Series Datasheet |
| Category | Power Supplies - External/Internal (Off-Board) | Voltage - Output 4 | - |
| Voltage - Output 3 | - | Voltage - Output 2 | -13.5V |
| Voltage - Output 1 | 13.5V | Voltage - Isolation | 3kV |
| Voltage - Input | 88 ~ 264 VAC, 125 ~ 373 VDC | Type | Enclosed |
| Size / Dimension | 3.90" L x 3.23" W x 1.42" H (99.0mm x 82.0mm x 36.0mm) | Series | RD-35 |
| Power (Watts) | 35W | Other Names | 1866-3982 RD-3513-ND |
| Operating Temperature | -25°C ~ 70°C (With Derating) | Number of Outputs | 2 |
| Mounting Type | Chassis Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Minimum Load Required | Yes | Manufacturer Standard Lead Time | 16 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Features | Adjustable Output, Universal Input |
| Efficiency | 80% | Detailed Description | Enclosed AC DC Converter 2 Output 13.5V -13.5V 1.3A, 1.3A 88 ~ 264 VAC, 125 ~ 373 VDC Input |
| Current - Output (Max) | 1.3A, 1.3A | Approvals | CB, CE, cURus, TUV |
| Applications | ITE (Commercial) |
