MDD01L-09
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy MDD01L-09 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy MDD01L-09 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | MDD01L-09 |
|---|---|
| Manufacturer | MEAN WELL |
| Description | DC DC CONVERTER +/-9V 1W |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $2.04 | $1.98 | $1.922 | $1.864 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | MDD01L-09 | Manufacturer | MEAN WELL |
|---|---|---|---|
| Description | DC DC CONVERTER +/-9V 1W | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 17800 pcs | Data sheet | MDS01, MDD01 Series Datasheet |
| Category | Power Supplies - Board Mount | Voltage - Output 4 | - |
| Voltage - Output 3 | - | Voltage - Output 2 | -9V |
| Voltage - Output 1 | 9V | Voltage - Isolation | 6000V |
| Voltage - Input (Min) | 4.5V | Voltage - Input (Max) | 5.5V |
| Type | Isolated Module | Supplier Device Package | 7-SIP |
| Size / Dimension | 0.77" L x 0.39" W x 0.49" H (19.5mm x 9.8mm x 12.5mm) | Series | MDD01 |
| Power (Watts) | 1W | Packaging | Tube |
| Package / Case | 7-SIP Module, 5 Leads | Other Names | 1866-3366 MDD01L-09-ND |
| Operating Temperature | -40°C ~ 85°C | Number of Outputs | 2 |
| Mounting Type | Through Hole | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 14 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Features | SCP | Efficiency | 81% |
| Detailed Description | Isolated Module DC DC Converter 2 Output 9V -9V 56mA, 56mA 4.5V - 5.5V Input | Current - Output (Max) | 56mA, 56mA |
| Applications | Medical |
