HLG-80H-36
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy HLG-80H-36 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy HLG-80H-36 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | HLG-80H-36 |
|---|---|
| Manufacturer | MEAN WELL |
| Description | LED DVR CC/CV ACDC 21.6-36V 2.3A |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | |||
|---|---|---|---|---|---|
| $13.449 | $12.152 | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | HLG-80H-36 | Manufacturer | MEAN WELL |
|---|---|---|---|
| Description | LED DVR CC/CV ACDC 21.6-36V 2.3A | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 2550 pcs | Data sheet | HLG-80H Series Datasheet |
| Category | Power Supplies - External/Internal (Off-Board) | Voltage - Output | 21.6 ~ 36 V |
| Voltage - Isolation | 3.75kV | Voltage - Input (Min) | 90VAC |
| Voltage - Input (Max) | 305VAC | Type | Constant Current, Voltage |
| Topology | AC DC Converter | Termination Style | Wire Leads |
| Size / Dimension | 6.76" L x 2.42" W x 1.53" H (171.8mm x 61.5mm x 38.8mm) | Series | HLG-80H |
| Ratings | IP67 | Power (Watts) | 83W |
| Other Names | 1866-2627 HLG-80H-36-ND |
Operating Temperature | -40°C ~ 80°C |
| Number of Outputs | 1 | Mounting Type | Chassis Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 16 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Features | OCP, OTP, OVP, SCP |
| Efficiency | 91% | Dimming | - |
| Detailed Description | 2.3A 21.6 ~ 36 V Constant Current, Voltage LED Driver AC DC Converter Topology 1 Output | Current - Output (Max) | 2.3A |
| Approvals | CB, CCC, CE, cULus, cURus, PSE, RCM, TUV, UL |
