HLG-100H-42B
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy HLG-100H-42B with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy HLG-100H-42B with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | HLG-100H-42B |
|---|---|
| Manufacturer | MEAN WELL |
| Description | LED DVR CC/CV AC/DC 21-42V 2.28A |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | ||
|---|---|---|---|---|---|
| $16.713 | $15.092 | $14.837 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | HLG-100H-42B | Manufacturer | MEAN WELL |
|---|---|---|---|
| Description | LED DVR CC/CV AC/DC 21-42V 2.28A | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 2587 pcs | Data sheet | HLG-120H Series Datasheet |
| Category | Power Supplies - External/Internal (Off-Board) | Voltage - Output | 21 ~ 42 V |
| Voltage - Isolation | 3.75kV | Voltage - Input (Min) | 90VAC |
| Voltage - Input (Max) | 305VAC | Type | Constant Current, Voltage |
| Topology | AC DC Converter | Termination Style | Wire Leads |
| Size / Dimension | 7.72" L x 2.68" W x 1.53" H (196.0mm x 68.0mm x 38.8mm) | Series | HLG-100H |
| Ratings | IP67 | Power (Watts) | 96W |
| Other Names | 1866-2311 HLG-100H-42B-ND |
Operating Temperature | -40°C ~ 80°C |
| Number of Outputs | 1 | Mounting Type | Chassis Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 16 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Features | OCP, OTP, OVP, SCP |
| Efficiency | 93% | Dimming | Analog, PWM |
| Detailed Description | 2.28A 21 ~ 42 V Constant Current, Voltage LED Driver AC DC Converter Topology 1 Output | Current - Output (Max) | 2.28A |
| Approvals | CB, CCC, CE, cURus, PSE, RCM, TUV |
