DCW12A-12
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy DCW12A-12 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy DCW12A-12 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | DCW12A-12 |
|---|---|
| Manufacturer | MEAN WELL |
| Description | DC DC CONVERTER +/-12V 12W |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $6.57 | $6.468 | $6.367 | $6.064 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | DCW12A-12 | Manufacturer | MEAN WELL |
|---|---|---|---|
| Description | DC DC CONVERTER +/-12V 12W | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 5240 pcs | Data sheet | DCW12 Series Datasheet |
| Category | Power Supplies - Board Mount | Voltage - Output 4 | - |
| Voltage - Output 3 | - | Voltage - Output 2 | -12V |
| Voltage - Output 1 | 12V | Voltage - Isolation | 1500V |
| Voltage - Input (Min) | 9V | Voltage - Input (Max) | 18V |
| Type | Isolated Module | Supplier Device Package | - |
| Size / Dimension | 1.25" L x 0.80" W x 0.48" H (31.8mm x 20.3mm x 12.2mm) | Series | DCW12 |
| Power (Watts) | 12W | Packaging | - |
| Package / Case | 24-DIP Module, 9 Leads | Other Names | 1866-1267 DCW12A-12-ND |
| Operating Temperature | -40°C ~ 71°C (With Derating) | Number of Outputs | 2 |
| Mounting Type | Through Hole | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 19 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Features | Remote On/Off, OCP, SCP | Efficiency | 84% |
| Detailed Description | Isolated Module DC DC Converter 2 Output 12V -12V 500mA, 500mA 9V - 18V Input | Current - Output (Max) | 500mA, 500mA |
| Applications | ITE (Commercial) |
