OCP-PCTB116/E
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy OCP-PCTB116/E with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy OCP-PCTB116/E with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | OCP-PCTB116/E |
|---|---|
| Manufacturer | Lumex, Inc. |
| Description | OPTOISO 5KV TRANS W/BASE 6DIP |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | Get a quote | ||||
- Product parameter
Product parameter
| Part Number | OCP-PCTB116/E | Manufacturer | Lumex, Inc. |
|---|---|---|---|
| Description | OPTOISO 5KV TRANS W/BASE 6DIP | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 5105 pcs | Data sheet | |
| Category | Isolators | Voltage - Output (Max) | 60V |
| Voltage - Isolation | 5000Vrms | Voltage - Forward (Vf) (Typ) | 1.2V |
| Vce Saturation (Max) | 300mV | Turn On / Turn Off Time (Typ) | - |
| Supplier Device Package | 6-DIP | Series | - |
| Rise / Fall Time (Typ) | 5µs, 4µs | Packaging | Tube |
| Package / Case | 6-DIP (0.300", 7.62mm) | Output Type | Transistor with Base |
| Other Names | 67-1563-5 | Operating Temperature | -30°C ~ 100°C |
| Number of Channels | 1 | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Input Type | DC | Detailed Description | Optoisolator Transistor with Base Output 5000Vrms 1 Channel 6-DIP |
| Current Transfer Ratio (Min) | 60% @ 2mA | Current Transfer Ratio (Max) | 600% @ 2mA |
| Current - Output / Channel | 50mA | Current - DC Forward (If) (Max) | 50mA |
