US6M2GTR
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy US6M2GTR with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy US6M2GTR with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | US6M2GTR |
|---|---|
| Manufacturer | LAPIS Semiconductor |
| Description | 2.5V DRIVE NCH+PCH MOSFET, 6 PIN |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 100 pcs | 500 pcs | 1000 pcs |
|---|---|---|---|---|---|
| $0.254 | $0.223 | $0.172 | $0.127 | $0.102 | |
- Product parameter
- Data sheet
Product parameter
| Part Number | US6M2GTR | Manufacturer | LAPIS Semiconductor |
|---|---|---|---|
| Description | 2.5V DRIVE NCH+PCH MOSFET, 6 PIN | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 197857 pcs | Data sheet | US6M2 |
| Category | Discrete Semiconductor Products | Vgs(th) (Max) @ Id | 1.5V @ 1mA, 2V @ 1mA |
| Supplier Device Package | TUMT6 | Series | - |
| Rds On (Max) @ Id, Vgs | 240 mOhm @ 1.5A, 4.5V, 390 mOhm @ 1A, 4.5V | Power - Max | 1W |
| Packaging | Original-Reel® | Package / Case | 6-SMD, Flat Leads |
| Other Names | US6M2GDKR | Operating Temperature | 150°C |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 10 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Input Capacitance (Ciss) (Max) @ Vds | 80pF @ 10V, 150pF @ 10V | Gate Charge (Qg) (Max) @ Vgs | 2.2nC @ 4.5V, 2.1nC @ 4.5V |
| FET Type | N and P-Channel | FET Feature | Standard |
| Drain to Source Voltage (Vdss) | 30V, 20V | Detailed Description | Mosfet Array N and P-Channel 30V, 20V 1.5A, 1A 1W Surface Mount TUMT6 |
| Current - Continuous Drain (Id) @ 25°C | 1.5A, 1A |
