SCT2H12NYTB
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy SCT2H12NYTB with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy SCT2H12NYTB with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | SCT2H12NYTB |
|---|---|
| Manufacturer | LAPIS Semiconductor |
| Description | 1700V 1.2 OHM 4A SIC FET |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 100 pcs | |
|---|---|---|---|---|---|
| $2.337 | $2.087 | $1.878 | $1.711 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | SCT2H12NYTB | Manufacturer | LAPIS Semiconductor |
|---|---|---|---|
| Description | 1700V 1.2 OHM 4A SIC FET | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 20670 pcs | Data sheet | SCT2H12NYTO-268-2L Taping Spec |
| Category | Discrete Semiconductor Products | Vgs(th) (Max) @ Id | 4V @ 410µA |
| Vgs (Max) | +22V, -6V | Technology | SiCFET (Silicon Carbide) |
| Supplier Device Package | TO-268 | Series | - |
| Rds On (Max) @ Id, Vgs | 1.5 Ohm @ 1.1A, 18V | Power Dissipation (Max) | 44W (Tc) |
| Packaging | Cut Tape (CT) | Package / Case | TO-268-3, D³Pak (2 Leads + Tab), TO-268AA |
| Other Names | SCT2H12NYTBCT | Operating Temperature | 175°C (TJ) |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Input Capacitance (Ciss) (Max) @ Vds | 184pF @ 800V |
| Gate Charge (Qg) (Max) @ Vgs | 14nC @ 18V | FET Type | N-Channel |
| FET Feature | - | Drive Voltage (Max Rds On, Min Rds On) | 18V |
| Drain to Source Voltage (Vdss) | 1700V | Detailed Description | N-Channel 1700V 4A (Tc) 44W (Tc) Surface Mount TO-268 |
| Current - Continuous Drain (Id) @ 25°C | 4A (Tc) |
