RS1G120MNTB
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy RS1G120MNTB with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy RS1G120MNTB with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | RS1G120MNTB |
|---|---|
| Manufacturer | LAPIS Semiconductor |
| Description | MOSFET N-CH 40V 12A 8HSOP |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 100 pcs | 500 pcs | 1000 pcs |
|---|---|---|---|---|---|
| $0.202 | $0.171 | $0.129 | $0.094 | $0.073 | |
- Product parameter
- Data sheet
Product parameter
| Part Number | RS1G120MNTB | Manufacturer | LAPIS Semiconductor |
|---|---|---|---|
| Description | MOSFET N-CH 40V 12A 8HSOP | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 296784 pcs | Data sheet | RS1G120MNHSMT8 TB Taping Spec |
| Category | Discrete Semiconductor Products | Vgs(th) (Max) @ Id | 2.5V @ 1mA |
| Vgs (Max) | ±20V | Technology | MOSFET (Metal Oxide) |
| Supplier Device Package | 8-HSOP | Series | - |
| Rds On (Max) @ Id, Vgs | 16.2 mOhm @ 12A, 10V | Power Dissipation (Max) | 3W (Ta), 25W (Tc) |
| Packaging | Cut Tape (CT) | Package / Case | 8-PowerTDFN |
| Other Names | RS1G120MNTBCT | Operating Temperature | 150°C (TJ) |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 40 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Input Capacitance (Ciss) (Max) @ Vds | 570pF @ 20V | Gate Charge (Qg) (Max) @ Vgs | 9.4nC @ 10V |
| FET Type | N-Channel | FET Feature | - |
| Drive Voltage (Max Rds On, Min Rds On) | 4.5V, 10V | Drain to Source Voltage (Vdss) | 40V |
| Detailed Description | N-Channel 40V 12A (Ta) 3W (Ta), 25W (Tc) Surface Mount 8-HSOP | Current - Continuous Drain (Id) @ 25°C | 12A (Ta) |
