RMW180N03TB
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy RMW180N03TB with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy RMW180N03TB with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | RMW180N03TB |
|---|---|
| Manufacturer | LAPIS Semiconductor |
| Description | MOSFET N-CH 30V 18A 8PSOP |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 100 pcs | 500 pcs | 1000 pcs |
|---|---|---|---|---|---|
| $0.465 | $0.411 | $0.325 | $0.252 | $0.199 | |
- Product parameter
- Data sheet
Product parameter
| Part Number | RMW180N03TB | Manufacturer | LAPIS Semiconductor |
|---|---|---|---|
| Description | MOSFET N-CH 30V 18A 8PSOP | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 119888 pcs | Data sheet | RMW180N03 |
| Category | Discrete Semiconductor Products | Vgs(th) (Max) @ Id | 2.5V @ 1mA |
| Vgs (Max) | ±20V | Technology | MOSFET (Metal Oxide) |
| Supplier Device Package | 8-PSOP | Series | - |
| Rds On (Max) @ Id, Vgs | 5.6 mOhm @ 18A, 10V | Power Dissipation (Max) | 3W (Ta) |
| Packaging | Cut Tape (CT) | Package / Case | 8-SMD, Flat Lead |
| Other Names | RMW180N03TBCT | Operating Temperature | 150°C (TJ) |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Input Capacitance (Ciss) (Max) @ Vds | 1250pF @ 15V |
| Gate Charge (Qg) (Max) @ Vgs | 24nC @ 10V | FET Type | N-Channel |
| FET Feature | - | Drive Voltage (Max Rds On, Min Rds On) | 4.5V, 10V |
| Drain to Source Voltage (Vdss) | 30V | Detailed Description | N-Channel 30V 18A (Ta) 3W (Ta) Surface Mount 8-PSOP |
| Current - Continuous Drain (Id) @ 25°C | 18A (Ta) |
